VELOTRIC DISCOVER 3 | TECHNICAL SPECIFICATIONS
SIZE GUIDE
Available Sizes: Regular / Large
Rider Height with Suspension Seatpost:
Regular: 5'2" – 5'11"
Large: 5'9" – 6'7"
Rider Height without Suspension Seatpost:
Regular: 4'11" – 5'9"
Large: 5'6" – 6'4"
FRAME & SUSPENSION
Frame: Triple-butted aluminum alloy, step-through
Front Fork: Air suspension, 80mm travel, lockout
Seatpost: 30.9mm aluminum alloy suspension seatpost
MOTOR, BATTERY & ELECTRONICS
Motor: 48V rear hub motor, 750W rated, 1,100W peak, 75Nm torque
Battery: 48V, 15.2Ah, 730Wh, IPX7 waterproof rating, UL 2271 certified
Battery Cells: Samsung/LG 21700, UL 2580 certified
Charger: 48V, 3A fast charger
Pedal Sensors: SensorSwap™ technology with selectable torque and cadence sensing
Pedal Assist: 5 assistance modes with app-based ride tuning
Throttle: Removable trigger throttle
Walk Mode: 2.9 mph, walk-and-hold operation
Display: 3.5" high-brightness color display with Bluetooth, NFC, and adjustable viewing angle
USB Port: USB-C phone charging
Connectivity: Smartphone app with over-the-air firmware updates and NFC card unlocking
Bike Finding: Apple Find My and Google Find Hub compatibility
Headlight: Integrated, adjustable 500-lumen LED
Rear Lighting: Integrated rack-mounted light with brake indication, turn signals, and steady/flash modes
Water Resistance: IPX6 bike/frame; IPX7 battery
SPEED & RANGE
Factory Top Speed: 20 mph
Configurable Pedal Assist Speed: 12–28 mph
E-Bike Classification: Configurable for Class 1, 2, or 3 operation
Maximum Pedal Assist Range: Up to 80 miles
Maximum Throttle Range: Up to 65 miles
Range Testing Conditions: 187 lb rider, Eco mode, flat roads
Actual range varies with terrain, rider weight, weather, speed, and assistance level.
DRIVETRAIN
Chainring: 46T narrow-wide
Crankset: 170mm aluminum alloy
Freewheel: 8-speed, 11–40T
Rear Derailleur: Shimano 8-speed
Shifter: Shimano 8-speed
Chain: KMC 8-speed
BRAKES & WHEELS
Brakes: Tektro hydraulic disc brakes
Brake Rotors: 180mm front and rear
Brake Levers: Aluminum alloy with motor power cutoff
Rims: Aluminum alloy
Front Hub: Novatec aluminum alloy, 15 x 110mm thru-axle
Tires: Kenda 27.5" x 2.4" puncture-resistant e-bike tires
COCKPIT & ACCESSORIES
Handlebar: Aluminum alloy, 31.8mm clamp diameter
Regular: 680mm wide
Large: 700mm wide
Grips: Lockable ergonomic grips
Stem: Adjustable aluminum alloy, 31.8mm clamp, 60mm length
Saddle: Velotric Comfort ergonomic saddle
Seatpost Clamp: Quick-release aluminum alloy
Fenders: Full-coverage aluminum alloy, front and rear
Rear Rack: MIK HD-compatible aluminum alloy
Pedals: Plastic
Kickstand: Rear-mounted aluminum alloy, included
WEIGHT & CAPACITY
Bike Weight: 61 lbs
Rear Rack Capacity: 66 lbs
Maximum Bike Load Capacity: 440 lbs (manufacturer-listed)
SAFETY & CERTIFICATIONS
Electrical System Certification: UL 2849
Battery Certification: UL 2271
Bicycle Safety Standard: ISO 4210
Manufacturer Warranty: 2 years
FRAME GEOMETRY
| Measurement | Regular | Large |
|---|
| Recommended Rider Height | 5'2"–5'11" | 5'9"–6'7" |
| Reach | 373mm | 373mm |
| Handlebar Height | 1,110mm | 1,110mm |
| Wheelbase | 1,113mm | 1,113mm |
| Stand-over Height | 400mm | 396mm |
| Minimum Saddle Height | 829mm | 900mm |
| Maximum Saddle Height | 985mm | 1,054mm |
| Overall Length | 1,818mm | 1,818mm |
Specifications are based on manufacturer-published information and are subject to change.
